Denon AVR-X2800H 7.2 Channel AV Receiver

7.2 Ch 8K AV Receiver

Enjoy incredible 8K video and immersive 3D audio from the AVR-X2800H. Fill medium-size rooms with more refined sound from a 7.2 or 5.2.2 set up with Dolby Atmos and DTS:X. And with HEOS® Built-in, wirelessly stream online music and share with HEOS-enabled speakers in other rooms.

Features

Powerful sound: Fill a medium-size room with powerful, more refined sound.

Immersive 3D audio: Feel fully enveloped in your music or movie sound.

Geared for 8K: Enjoy amazing video quality from the latest 8K technology available.

Music streaming throughout your home: With HEOS® Built-in, easily access streaming music and share with HEOS-enabled speakers in other rooms.

High Performance Discrete 7-Channel Amplifier

Discrete high-current amplifiers on all channels to deliver up to 95W per channel (at 8 ohms, 20 Hz - 20 kHz, THD 0.08%) — enough power to drive any speaker.

Immersive Audio Experience

Get immersed in music and movies with Dolby Atmos® and DTS:X® plus Dolby Surround and DTS Neural:X upmixer to optimise legacy content.

Advanced 8K Home Theatre

8K video is supported on three of six HDMI inputs and two outputs. Enjoy easy video compatibility and great picture quality with HLG, HDR, Dolby Vision, HDR10+, and Dynamic HDR passthrough.

HEOS® Built-In Technology

Stream music wirelessly to compatible HEOS-enabled components from a variety of streaming services. Add Denon Home speakers to more rooms and control it all with the HEOS app.

Dolby Atmos

Feel every dimension in Dolby Atmos. Upgrade your home theatre with height speakers to unleash a fully immersive 3D audio experience from Dolby Atmos content. Dolby Surround upmixer engages all speakers to create 3D audio sensation from legacy content. Dolby Atmos Height Virtualization Technology creates the sensation of overhead sound even without height speakers. You can also enjoy Dolby Atmos music tracks available from Apple Music, Amazon HD, and TIDAL and a compatible streaming device.

DTS:X

DTS:X immersive audio content places sound where it would naturally occur in space, creating lifelike, multidimensional audio. DTS Neural:X upmixer offers improved immersion and heightened realism for legacy content. DTS Virtual:X provides immersive audio without height channels, creating virtual height effects in a 7.1, 5.1, or 2.1 speaker setup.

HDMI Connectivity with ARC/eARC

Supports the latest technology on all HDMI inputs and output. ARC (Audio Return Channel) or eARC (Enhanced Audio Return Channel) makes playing TV audio through your AV receiver simple, with just a single HDMI connection. eARC provides HD and 3D audio transmission such as Dolby TrueHD, DTS HD Master Audio, and Dolby Atmos while ARC is limited to conventional 5.1ch audio formats or PCM.

8K / HDCP 2.3

Enjoy pristine 8K picture quality on your 8K TV or projector. Supports both 8K pass-through and 8K upscaling of 4K content. Supports HDCP 2.3, the latest copy protection standard, for peace of mind when streaming copy protected content.

Brilliant Colour From HDR 10+

Supports HDR (High Dynamic Range), HLG (Hybrid Log Gamma), as well as Dynamic HDR and HDR10+ pass-through. HLG offers HDR technology over broadcast content. Both Dynamic HDR and HDR10+ use dynamic metadata to optimise shadows and highlights as screens change.

Dolby Vision

Dolby Vision is a stunning HDR imaging technology that brings extraordinary colour, contrast, and brightness to the screen. Compatible with Dolby Vision so you can enjoy Dolby Vision content from a compatible source device and TV.

Next-Generation Gaming

Supports Variable Refresh Rate (VRR), Quick Frame Transport (QFT), and Auto Low Latency Mode (ALLM) for smooth, lag free gaming experience when connected with the compatible gaming devices.

HEOS Built-In

With HEOS® Built-in, your AV receiver can stream music wirelessly across compatible HEOS components from a variety of free and premium streaming services. Consumers can also enjoy their favourite music in any room of the home wirelessly. Play the same song in every room or select a different song for each connected room via a variety of streaming sources. Add Denon Home speakers to more rooms and control it all with the HEOS app.

AirPlay 2 and Apple Siri Voice Control

Use AirPlay 2 to stream Apple music wirelessly to the AV receiver, or group with other AirPlay compatible speakers to fill your home with music.

Works with Amazon Alexa

Control your AV receiver hands-free with Amazon Alexa and your voice. Adjust the volume, skip to the next track, switch inputs for your different media players, and more—“Just Ask.” Download the free HEOS Home Entertainment Skill to enable Amazon Alexa voice commands. Requires Alexa app and Amazon Echo, Dot, or equivalent.

High-Resolution Audio via USB Input

Discover the incredible fidelity of high-resolution audio tracks and enjoy music as the artist intended. A front USB port supports up to 24bit/192kHz hires audio playback from a USB drive. Supported audio formats are MP3, WMA, WAV, MPEG-4/AAC, FLAC, and ALAC.

Bluetooth Audio Transmitter

Pair your favourite Bluetooth headphones with your AV receiver to continue listening to your favourite music, movies, or TV programs at night. You can also play audio from both speakers and Bluetooth headphones simultaneously. If you have a family member or a friend who is hearing impaired, we recommend this setup. You can connect one pair of headphones at a time.

Multi-Source, Multi-Room

By connecting a pair of speakers in a second room to the AV receiver, it’s possible to enjoy 5.1 channel surround sound in the main room and a separate source or music stream in the second room, such as den or patio. You can also play the same audio in both so that everyone in your home can enjoy and cheer your favourite team on Sunday evening or listen to the same song in both rooms. The AV receiver supports 2-source, 2-zone audio.

Denon Setup Assistant

Award-winning guide Denon Setup Assistant supplies simple, clear instructions to get started. Just connect your AV receiver to your TV and follow the instructions on the TV screen to connect your speakers, perform speaker measurements, and connect source devices. For additional convenience, the AV receiver renames HDMI inputs automatically when connected or you can rename manually at your convenience.

Audyssey Suites of Room Correction Technology

Denon AV receivers use the Audyssey suite of EQ software for simple, accurate setup and calibration. With the supplied Audyssey measuring microphone, Audyssey measures all the speakers in your home theatre, and tunes the AV receiver to provide the smoothest, most optimal overall listening experience for your room. This AV receiver supports Audyssey MultEQ room-correction technology. The other supported Audyssey features are Dynamic EQ and Dynamic Volume.

Audyssey MultEQ Editor App

You can go even further with the Audyssey MultEQ Editor app, going “under the hood” to view and adjust settings for detailed tuning—allowing you to customise the sound more precisely to the specific problems in your room and tailor the sound to your personal preferences. With this comprehensive app, you can harness the power of Audyssey MultEQ to take total control of the way your home cinema sounds. The app is available for purchase in iOS and Google Play stores.

Denon AVR Remote App

This iOS or Android control app allows you to turn the receiver on and off, select an input source, adjust volume level, and browse music from your phone or in a USB drive when connected to the receiver.

Works with Google Assistant

Start music in the HEOS app, then ask your Google Assistant to control volume, play, pause,skip tracks, mute, and unmute.

Specifications

Multichannel Surround

DTS-HD Master / DTS:X / DTS:X Pro ✓ / ✓ / -

DTS Neo:X / DTS Neural:X - / ✓

DTS Virtual:X ✓

IMAX Enhanced ✓

Dolby TrueHD / Dolby Atmos / Dolby Atmos Height Virtualization / Dolby Atmos Music ✓ / ✓ / ✓ / ✓

Dolby ProLogic Ilz / Dolby Surround - / ✓

Auro 3D -

360 Reality Audio / MPEG-H - / -

Multichannel Stereo ✓

Max Number of Processing (Preamp) Channels 7.1

Sound Enhancements

Discrete Power Amplifier ✓

Pure Direct ✓

Audyssey MultEQ XT

Audyssey Dynamic EQ / Dynamic Volume ✓ / ✓

Audyssey LFC -

Dirac Live Upgradability -

Compressed Audio Restorer ✓

Network

Media Server ✓

HEOS Wireless Multi-Room Technology ✓

Alexa / Google Voice Assistant / Apple HomePod ✓ / ✓ / ✓

Lossy Formats: MP3 / WMA / AAC ✓ / ✓ / ✓

Lossless Formats: FLAC / ALAC / WAV ✓ / ✓ / ✓

Lossless Formats: FLAC HD / WAV / ALAC (All 192 kHz / 24 Bit) ✓ / ✓ / ✓

DSD Audio Streaming ✓ (2.8/5.6 MHz)

AirPlay 2 ✓

TuneIn ✓

Spotify Connect ✓

Roon Tested ✓

HEOS App Control ✓

Compatible with Remote App for Smart Phones ✓ (Denon 2016 AVR Remote)

Ethernet Ports ✓

Wi-Fi ✓

Bluetooth ✓

HDMI

HDMI Inputs: Back / Front 6 / -

HDCP 2.3 Support ✓

HDMI Outputs: Main / Zone 2 / -

HDMI 2.1: 8K 60 Hz AB / 4K 120 Hz AB ✓ / ✓

HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR ✓ / ✓ / ✓ / ✓ / ✓

ALLM (Auto Low Latency Mode) Pass-Through for Gaming ✓

Variable Refresh Rate / Quick Frame Transport / Quick Media Switching ✓ / ✓ / ✓

3D Signal Pass-Through ✓

8K Signal Pass-Through / Scaling / GUI Overlay ✓ / ✓ / ✓

Audio Return Channel (ARC) / Enhanced Audio Return Channel (eARC) ✓ / ✓

Auto LipSync ✓

Multiroom / CI

Multi-Room Zones 2

Zone Audio Source: HDMI / Optical, Coax / Network, USB / Analogue ✓ (2 Ch) / ✓ (2 Ch) / ✓ / ✓

Zone Audio Output: Speaker / Preout ✓ / ✓

Zone HDMI Output from HDMI Source -

IP Control / RS232 Control / Web Control / App Control ✓ / - / ✓ / ✓

HDMI Diagnostics ✓

Others

Auto Speaker Setup by Microphone Audyssey MultEQ XT

Front Display 1 Line FLD

GUI Languages 3

Setup Assistant ✓

Quick Select Plus / Quick Select ✓ / -

Variable Crossover ✓

Optimised Bass Redirection ✓

ECO Mode ✓

Auto Power Off ✓

Sleep Timer ✓

Inputs / Outputs

HDMI In / Out 6 / 2

Multi-Room Video Out: Video / HDMI - / -

Analogue In / Out 4 / -

Phono (MM) In ✓

Digital In: Optical / Coaxial 2 / -

Multi-Room Out: Analogue / Digital 1 / -

Multichannel Preout ✓ (0.2)

Subwoofer Out 2

Speaker Terminal: Gold Plated Screw / Regular Screw - / ✓

Number of Speaker Terminals 7

Speaker A/B Assignable

Bi-Amp Drive Assignable

Multi-Room Speaker Terminal Assignable

Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB - / - / - / - / ✓

USB Audio / Made for iPod / Made for iPhone ✓ / - / -

AM/FM Tuner ✓

Specifications

Number of Power Amps 7

Power Output (8 Ohm, 20 Hz - 20 kHz, 0.08% THD, 2 Ch Driven) 95 W

Power Output (6 Ohm, 1 kHz, 0.7% THD, 2 Ch Driven) 125 W

Power Output (6 Ohm, 1 kHz, 10% THD, 1 Ch Driven) 185 W

General

System Remote Control RC-1253

Pre-Programmed / Learnable / LCD Display - / - / -

Power Consumption 500 W

Power Consumption No-Sound (ECO On / Off) 35 W / 75 W

Standby Consumption 0.1 W

CEC Standby Consumption 0.5 W

Network Standby Consumption Less Than 2.0 W

Dimensions - Antenna: Horizontal (W x D x H) 434 x 341 x 167 mm

Dimensions - Antenna: Vertical (W x D x H) 434 x 341 x 237 mm

Dimensions - No Antenna (W x D x H) 434 x 330 x 167 mm

Weight 9.5 kg

Weight in Packaging 11.5 kg
