Luxman D-10X SACD/CD Player

Our flagship SACD/CD player, the D-10X builds on the brilliant heritage of our acclaimed D-08u, adding more playback capabilities, the latest conversion technology, a robustly reinforced mechanism and a refined analog output stage.

Introducing LxDTM-i – the LUXMAN original Disc Transport Mechanism (improved). Introducing ODNF-u – Only Distortion Negative Feedback (ultimate) – in a fully balanced output amplifier. Well-grounded in fundamental principles and endowed with the most advanced mechanical, digital and analog technology, the LUXMAN D-10X opens the curtain on the ultimate soundstage.

You select your listening position carefully. The 4X zoom function makes the fluorescent display easy to read from that seat. When playing MQA-CDs and files, a three-color indicator confirms decode status: Studio (blue), Authentic (green) and Renderer (magenta).

The supplied aluminum remote control has the same blasted white finish as the player's front panel. Without leaving the ideal listening position, you can use the numeric keypad, transport controls and display dimmer.

For playing back music from a PC, we recommend our LUXMAN Audio Player application. This software supports FLAC, ALAC, WAV, AIFF, MP3, DSF and DSDIFF files. You can download the software for Windows and macOS from the official LUXMAN website.

Specifications

Supported discs    SACD, CD (CD-R, CD-RW, MQA-CD)

Supported sampling frequencies    USB input (PCM) : 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz, 352.8 kHz, 384 kHz,

705.6 kHz, 768 kHz (16, 24, 32-bit)

USB input (DSD) : 2.8 MHz, 5.6 MHz, 11.2 MHz, 22.4 MHz (1-bit)

Coaxial / Optical input : 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz, 192 kHz (16, 20, 24-bit)

Analog output voltage / impedance Unbalanced : 2.4 V / 300 Ω, Balanced : 2.4 V / 600 Ω

For SACD / DSD : 1.3 V

Frequency response CD : 5 Hz to 20 kHz (+0, -1.0 dB)

SACD : 5 Hz to 38 kHz (+0, -3.0 dB)

USB : 5 Hz to 47 kHz (+0, -3.0 dB)

Total harmonic distortion CD : 0.0018 %, SACD : 0.001 %, USB : 0.0015 %

S/N ratio (IHF-A) CD : 125 dB, SACD : 121 dB, USB : 125 dB

D/A converter ROHM BD34301EKV (monaural mode) x 2

Power supply 230 V～(50 Hz) / 115 V～ (60 Hz)

Power consumption 48W

Dimensions 440(W) x 154(H) x 418(D) mm

front side knob of 2 mm and rear side terminal of 13 mm included in depth

Net weight 22.4 kg

Accessories Remote control (RD-29), Power cable
