Specifications
Frequency Response: 52Hz - 23kHz +/- 3dB
High Frequency Driver: 1" (2.54cm) Titanium Dome Tweeter mated to a composite coated round Tractrix® Horn
Low Frequency Driver: 8" (16.51cm) Cerametallic Woofer
Sensitivity: 96 dB @ 2.83V / 1m
Coverage Angle: 100°
Power Handling: 50W RMS / 200W Peak
Impedance: 8 Ohm Compatible
Enclosure Type: ABS/Infinite Baffle
Finish: Black Baffle/Frame, White Paintable Grille
Product Dimensions: 10.75” W x 10.75” H x 4.5” D (27.3cm H x 27.3cm W x 11.5cm D)
Mounting Depth: 4.45” (11.3cm)
Cutout Dimensions: 9.8” (24.9cm)
Product Weight: 7.4 lbs (3.36kg)
Included: Round Grille, Square Grille, Paint Shield
Installation Kit: IK-800-C (Sold Separately)
