Features
Cerametallic™ Woofer
Ported ABS Baffle
Fire-rated Back Box
Titanium Dome tweeter with Round Tractrix Horn
Specifications
Frequency Response: 90Hz – 20kHz
Power Handling: 120W Peak
Recommended Amp Power: 50W
Sensitivity: 91dB
Nominal Impedance: 8 Ohm
High Frequency Driver: 1” (2.5cm) Titanium Dome Tweeter with Round Tractrix Horn
Low Frequency Driver: 4” (10.2cm) Cerametallic™ Woofer
Enclosure Type: 50mm Deep Metal Back Box with Ported ABS Baffle
Wire Gauge Recommended: 12 Gauge
Product Diameter: 9.5” (24.13cm)
Cutout Dimensions: 8.3” (21cm)
Mounting Depth: 48mm (1.89 in)
Installation Kit: IK-650-C (Sold Separately)
Product Weight: 7.4 lbs
