Magico A3 Floorstanding Loudspeakers

The A3 borrows heavily from the leading-edge concepts and technology found in the rest of the line, making the A3 an outstanding value. As an example, the A3 enclosure is made entirely from 6061 T6 aircraft-grade aluminum—the same material used by the enclosures of the Q Series. The simple rectangular shape and brushed, anodized finish reduces cost while optimizing performance and value.


The A3 is a three-way, four-driver design consisting of 28mm tweeter, 6” midrange and dual 7” woofers combine to produce an impressive 22Hz to 50kHz frequency response.


The tweeter uses a pure beryllium diaphragm and takes its basic design and geometry from Magico’s limited edition M-Project’s tweeters. The 6” midrange driver uses a carbon fiber cone coated with XG Nanographene and extra-large magnets to create a more stabilized field. The speaker’s low end is handled by two 7-inch woofers that incorporate an updated version of Magico’s Nano-Tec cones (also found on the M Project), which use carbon nanotubes in their construction.

High-Frequency driver


Extended high frequencies are provided by a newly designed MAGICO pure beryllium-diaphragm tweeter with an optimized 28-mm dome surface based on the fundamental design platform and geometry of the M-Project tweeter. The customized neodymium motor system is encased in an improved back chamber with our latest generation damping materials that facilitate ultra-low distortion, higher power handling, massive dynamic capabilities, and extended linear voice coil movement.


Midrange Frequency driver


The newly developed 6-inch midrange employs a Multi-Wall carbon fiber cone with a layer of XG Nanographene, providing optimal stiffness to weight ratios and an ideal damping factor. Overhung neodymium-based motor systems incorporate extra-large magnets to ensure a stabilized magnetic field in the 75-mm pure titanium voice coils of both the midrange and bass drivers.


Low-Frequency Drivers


Dual 7-inch woofers incorporate a version of the new Gen 8 MAGICO Nano-Tec cone. The same properties and materials that allow for the proper combination of stiffness, mass, and damping are carried through to the lowest frequencies. The chassis has also been simulated and tested for the optimal combination of stiffness and damping. Minimum acoustical impact is achieved by reducing vibration modes while maximizing air flow. A new overhung neodymium (N48) based motor system anchors the low-frequency reproducers to accomplish a super stabilized magnetic field. A pure Titanium, 75mm voice coils are consistent with the technology utilized through the midrange.


The A3 Midrange and Low-frequency drivers were optimized for minimal music related distortions in its bandpass, in both the frequency and time domains using the latest state of the art FEA simulation of acoustical, mechanical, electromagnetic and thermal behavior. All of this is now being done on a single platform, allowing Magico to take the next step in performance optimization.

Specifications
Driver Complement:
1 X 1.1” (2.79cm) Beryllium Dome Tweeter
1 X 6” (15.24cm) Graphene Nano-Tec Midrange
2 X 7” (17.78cm) Graphene Nano-Tec Bass

Sensitivity: 88dB

Impedance: 4 Ohms

Frequency Response:
22 Hz – 50 KHz

Recommended Power:
50 watt RMS (min) / 300 watts (max)

Dimensions:
44”H x 11”D x 9.25”W (112cm x 27cm x 23cm)

Weight: 110 lbs. (49.89 kg)
