Features:
Specifications
Frequency Range: 56Hz - 23kHz +/- 3dB
High Frequency Driver: 1" (2.54cm) Aluminum Dome Tweeter mated to a 90°x90° Tractrix® Horn
Low Frequency Driver: Dual 5.25" (13.34cm) IMG Woofers
Sensitivity: 93 dB @ 2.83V / 1m
Coverage Angle: 90° x 90°
Power Handling: 75W RMS / 300W Peak
Impedance: 8 Ohm Compatible
Enclosure Type: ABS/Infinite Baffle
Finish: Black Baffle/Frame, White Paintable Grille
Product Dimensions: 7.5” W x 17.4” H x 3.8” D (19.1cm H x 44.2cm W x 9.6cm D)
Mounting Depth:3.78” (9.35cm)
Cutout Dimensions: 16.5” H X 6.5” W (41.9cm H X 16.5cm W)
Product Weight: 6.5lbs (2.95kg)
Included: Grille, Paint Shield
Installation Kit: IK-502-W II or IK-502-W (Sold Separately)
