Features:
Specifications
Frequency Range: 56Hz - 23kHz +/- 3dB
High Frequency Driver: 1" (2.54cm) Aluminum Dome Tweeter mated to a 90°x90° Tractrix® Horn
Low Frequency Driver: 8" (20.32cm) IMG Woofer
Sensitivity:95 dB @ 2.83V / 1m
Coverage Angle: 90° x 90°
Power Handling: 50W RMS / 200W Peak
Impedance: 8 Ohm Compatible
Enclosure Type: ABS/Infinite Baffle
Finish: Black Baffle/Frame, White Paintable Grille
Product Dimensions: 10.16” W x 15.75” H x 4.0” D (25.8cm H x 40.0cm W x 10.1cm D)
Mounting Depth: 3.9” (9.9cm)
Cutout Diameter: 14.8” H X 9.25” W (37.5cm H X 23.5cm W)
Product Weight: 7.9lbs (3.6kg)
Included: Grille, Paint Shield
Installation Kit: IK-800-W II or IK-800-W (Sold Separately)
