Ortofon 2MR Red Moving Magnet Cartridge

Specially Made for Rega Tonearms and Turntables: Ortofon 2MR Red Sets the Standard for Entry-Level High-End Moving-Magnet Phono Cartridges

Built with a specially designed narrow cartridge housing tailored for Rega turntables and tonearms that require low form-factor cartridges, Ortofon 2MR Red MM seamlessly integrates with Rega platforms without any need for modifications or spacers under the tonearm. Best of all, it retains every performance and material characteristic of the original 2M Red.

And that’s a very good thing, given 2MR Red is as good as audiophile-grade moving-magnet types come at its price point. Open, slightly warm, and a truly all-purpose design, 2MR Red uses a tipped elliptical diamond stylus and rubber dampers for accurate retrieval of the information in the record groove.

Ortofon's trademark quad-coils motor system and split pole pins enable flat frequency response, just like that of a moving-coil cartridge. An improved engine provides an increased output of 5.5mV. Plus, it is compatible with Ortofon 2M replacement styli and mounts easily and quickly, via two screws.

Features

The 2M Red features a tipped Elliptical diamond and split pole pins with a copper wire.

The engine provides an increased output of 5.5 mV and an optimized sound reproduction and a high level of sonic accuracy.

Designed for easy mounting of the cartridge, and for the weight and size to fit the most common turntables on the market today. The 2M Series provides excellent compatibility when used in an assortment of playback systems and with a wide variety of phono preamps.

2M Red delivers an open, dynamic sound with a slight touch of warmth.

Specifications

Output voltage at 1000 Hz, 5cm/sec. - 5.5 mV

Channel balance at 1 kHz - 1.5 dB

Channel separation at 1 kHz - 22 dB

Channel separation at 15 kHz - 15 dB

Frequency response - 20-20.000 Hz + 3 / - 1 dB

Tracking ability at 315Hz at recommended tracking force - 70 µm

Compliance, dynamic, lateral - 20 µm/mN

Stylus type - Elliptical

Stylus tip radius - r/R 8/18 µm

Tracking force range - 1.6-2.0 g (16-20 mN)

Tracking force, recommended - 1.8 g (18 mN)

Tracking angle - 20°

Internal impedance, DC resistance - 1.3 kOhm

Internal inductance - 700 mH

Recommended load resistance - 47 kOhm

Recommended load capacitance - 150-300 pF

Cartridge colour, body/stylus - Black/Red

2MR cartridge weight - 6 g

2M and 2M Verso cartridges weight - 7.2 g

2M Premounted cartridge weight - 16.7 g
