Velodyne Impact X 15" Subwoofer

Full Power Design!

The Impact X series creates a lasting impression with amazing low frequency sound. The subwoofers’ attractive MDF enclosure in black and white finish also blends beautifully with modern interiors. The music and home theatre experience in specific from the smallest possible package benefits enormously from the completely redesigned 10- and 12-inch drivers, which set new standards in this price range. A highly efficient Class D amplifier, along with core technologies from Velodyne Acoustics, minimises distortion and makes amazing bass performance possible.

Now, a 15-inch subwoofer also expands the Impact X line. It features a special flow-optimised rear slot design that is used as a bass reflex. With a lower frequency limit of 19 Hertz and 9 DSP modes that also bring room modes under control, it is especially designed for demanding home theatre applications and large living rooms.

These powerful subwoofers combine efficient front-firing drivers with a down-firing/rear-firing bass reflex port.

Impact: The name says it all. And this all-new design really has the X factor!

Featuring unprecedented technology and performance for the price point, these solidly constructed subwoofers feature 20mm thick MDF cabinets and all new 10", 12" and 15" woofer design.

With up to 1000 Watts peak amplifier power (15" model) and down firing bass reflex port, the performance is sublime. Velodyne's advanced anti-clipping circuitry ensures distortion is kept to a bare minimum for clean bass.

The technology behind the Impact X is another area where Velodyne again demonstrates they are the market leader. Full function remote control, front screen (with adjustable light level) and integrated DSP presets make this an incredibly capable range.

The amplifier has been thoughtfully designed and features loop though for those customers wishing to run multiple subwoofers in their room.

Features

MDP Amplifier - Maximum Dynamic Power class D amplifier with up to 1000 watts peak dynamic headroom (Impact X 15)

Remote Control - The included full-feature remote control makes setup a breeze from the convenience of your seat

Down Ported Design - Maximum impact is achieved through a down firing port

Front Display Screen - Keep in touch with the settings from the easy to read front display screen

Four Layer Voice Coil - The drivers feature 76mm four layer voice coils with high excursion double vented baskets for maximum performance

Integrated DSP - Four distinct signal processing presets are adjustable via the included remote to get the best setup for your preferences

Specifications

Driver: 15" Forward Firing

Amplifier:

Class D

1000 Watts Dynamic

550 Watts RMS

Frequency Response (Overall): 18 - 220Hz

Frequency Response (± 3 dB): 23 - 180Hz

Cabinet Design: Rear Slot Ported 20mm MDF

High Pass Crossover: Full Range

Low Pass Crossover: 50 - 180Hz Adjustable (12dB/Octave)

Phase: Adjustable 0/180 degrees

Magnet Structure: Dual Ferrite Motor

Voice Coil: Four Layer, 76mm

Cone: 15” high excursion double vented basket driver with pp Membrane and convex cone

Outputs: Gold Plated Stereo/LFE RCA

Inputs:

Gold Plated Stereo/LFE RCA

Nickel plated speaker level

Grille: Fabric over round MDF frame

Power: On / Off / Auto

Dimensions (H x W x D) Including Feet & Connectors: 48 x 44 x 59 cm

Weight: 35kg

Shipping Weight: 40kg
